1500W Switching Power Supply AC-DC SMPS Output 12V 15V 24V 36V 48V 50V 60V 72V 80V 90v dc Power Supply (Input Voltage : 220V, Output Voltage : 13.8V 108A)

1500W Switching Power Supply AC-DC smps output 12V 15V 24V 36V 48V 50V 60V 72V 80V 90v dc power supplyOther voltage, please contact with us.Model Specification S-1500-12S-1500-13.5S-1500-15S-1500-24S-1500-27S-1500-48DC Output voltage(V)1213.515242748Rated output current(A)12511010062.55531Output current range(A)0~1250~1100~1000~62.50~550~31Wave and noise(mVp-p)200200200200200200Inlet stability(%)±0.5±0.5±0.5±0.5±0.5±0.5Load stability(%)±0.5±0.5±0.5±0.5±0.5±0.5DC output power(W)150015001500150015001500Efficiency(%)84848585.586.587AC input voltage range200~240VAC 47~63Hz ( 220Vac or 110vac, when you make order please choose it.)Input current7A/230VAC Inrush current50A/230VLeakage current<;3.5mA/240VACOverload protection105%-150% Type:pulsing hiccup shutdown Reset:auto recoveryOver-voltage protection13.8~16.2v15.5~18.2v18~21v27.6~32.4v31~36.5v57.6~67.2vHigh-temperature protection≥70°C Cut off output(0~50°C)Temperature coefficient±0.03%/°C(0~50°C)Setup, rise, hold up time1.5s, 50ms, 20msVibration10~500Hz, 2G 10min,/1 cycle. Period for 60min,Each axesWithstand voltageI/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVACIsolation resistanceI/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDCWorking temperature and humidity-10°C~+60°C,10%~95%RHStore temperature and humidity-20°C~+85°C,10%~95%RH
